16-bit table chip for SHA-256

This chip implementation is based around a single 16-bit lookup table. It requires a minimum of 2^{16} circuit rows, and is therefore suitable for use in larger circuits.

We target a maximum constraint degree of 9. That will allow us to handle constraining carries and "small pieces" to a range of up to \{0..7\} in one row.

Compression round

There are 64 compression rounds. Each round takes 32-bit values A, B, C, D, E, F, G, H as input, and performs the following operations:

\begin{array}{rcl} Ch(E, F, G) &=& (E \wedge F) \oplus (¬E \wedge G) \ Maj(A, B, C) &=& (A \wedge B) \oplus (A \wedge C) \oplus (B \wedge C) \ &=& count(A, B, C) \geq 2 \ \Sigma_0(A) &=& (A ⋙ 2) \oplus (A ⋙ 13) \oplus (A ⋙ 22) \ \Sigma_1(E) &=& (E ⋙ 6) \oplus (E ⋙ 11) \oplus (E ⋙ 25) \ H' &=& H + Ch(E, F, G) + \Sigma_1(E) + K_t + W_t \ E_{new} &=& reduce_6(H' + D) \ A_{new} &=& reduce_7(H' + Maj(A, B, C) + \Sigma_0(A)) \end{array}

where reduce_i must handle a carry in \{0, \ldots, i-1\}.

Define \mathtt{spread} as a table mapping a $16$-bit input to an output interleaved with zero bits. We do not require a separate table for range checks because \mathtt{spread} can be used.

Modular addition

To implement addition modulo 2^{32}, we note that this is equivalent to adding the operands using field addition, and then masking away all but the lowest 32 bits of the result. For example, if we have two operands a and b:

a \boxplus b = c,

we decompose each operand (along with the result) into 16-bit chunks:

(a_L : \mathbb{Z}_{2^{16}}, a_H : \mathbb{Z}_{2^{16}}) \boxplus (b_L : \mathbb{Z}_{2^{16}}, b_H : \mathbb{Z}_{2^{16}}) = (c_L : \mathbb{Z}_{2^{16}}, c_H : \mathbb{Z}_{2^{16}}),

and then reformulate the constraint using field addition:

\mathsf{carry} \cdot 2^{32} + c_H \cdot 2^{16} + c_L = (a_H + b_H) \cdot 2^{16} + a_L + b_L.

More generally, any bit-decomposition of the output can be used, not just a decomposition into 16-bit chunks. Note that this correctly handles the carry from a_L + b_L.

This constraint requires that each chunk is correctly range-checked (or else an assignment could overflow the field).

• The operand and result chunks can be constrained using \mathtt{spread}, by looking up each chunk in the "dense" column within a subset of the table. This way we additionally get the "spread" form of the output for free; in particular this is true for the output of the bottom-right \boxplus which becomes A_{new}, and the output of the leftmost \boxplus which becomes E_{new}. We will use this below to optimize Maj and Ch.

• \mathsf{carry} must be constrained to the precise range of allowed carry values for the number of operands. We do this with a small range constraint.

Maj function

Maj can be done in 4 lookups: 2\; \mathtt{spread} * 2 chunks

• As mentioned above, after the first round we already have A in spread form A'. Similarly, B and C are equal to the A and B respectively of the previous round, and therefore in the steady state we already have them in spread form B' and C'. In fact we can also assume we have them in spread form in the first round, either from the fixed IV or from the use of \mathtt{spread} to reduce the output of the feedforward in the previous block.
• Add the spread forms in the field: M' = A' + B' + C';
  • We can add them as $32$-bit words or in pieces; it's equivalent
• Witness the compressed even bits M^{even}_i and the compressed odd bits M^{odd}_i for i = \{0..1\};
• Constrain M' = \mathtt{spread}(M^{even}_0) + 2 \cdot \mathtt{spread}(M^{odd}_0) + 2^{32} \cdot \mathtt{spread}(M^{even}_1) + 2^{33} \cdot \mathtt{spread}(M^{odd}_1), where M^{odd}_i is the Maj function output.

Note: by "even" bits we mean the bits of weight an even-power of 2, i.e. of weight 2^0, 2^2, \ldots. Similarly by "odd" bits we mean the bits of weight an odd-power of 2.

Ch function

TODO: can probably be optimised to 4 or 5 lookups using an additional table.

Ch can be done in 8 lookups: 4\; \mathtt{spread} * 2 chunks

• As mentioned above, after the first round we already have E in spread form E'. Similarly, F and G are equal to the E and F respectively of the previous round, and therefore in the steady state we already have them in spread form F' and G'. In fact we can also assume we have them in spread form in the first round, either from the fixed IV or from the use of \mathtt{spread} to reduce the output of the feedforward in the previous block.
• Calculate P' = E' + F' and Q' = (evens - E') + G', where evens = \mathtt{spread}(2^{32} - 1).
  • We can add them as $32$-bit words or in pieces; it's equivalent.
  • evens - E' works to compute the spread of ¬E even though negation and \mathtt{spread} do not commute in general. It works because each spread bit in E' is subtracted from 1, so there are no borrows.
• Witness P^{even}_i, P^{odd}_i, Q^{even}_i, Q^{odd}_i such that P' = \mathtt{spread}(P^{even}_0) + 2 \cdot \mathtt{spread}(P^{odd}_0) + 2^{32} \cdot \mathtt{spread}(P^{even}_1) + 2^{33} \cdot \mathtt{spread}(P^{odd}_1), and similarly for Q'.
• \{P^{odd}_i + Q^{odd}_i\}_{i=0..1} is the Ch function output.

Σ_0 function

\Sigma_0(A) can be done in 6 lookups.

To achieve this we first split A into pieces (a, b, c, d), of lengths (2, 11, 9, 10) bits respectively counting from the little end. At the same time we obtain the spread forms of these pieces. This can all be done in two PLONK rows, because the 10 and $11$-bit pieces can be handled using \mathtt{spread} lookups, and the $9$-bit piece can be split into $3 * 3$-bit subpieces. The latter and the remaining $2$-bit piece can be range-checked by polynomial constraints in parallel with the two lookups, two small pieces in each row. The spread forms of these small pieces are found by interpolation.

Note that the splitting into pieces can be combined with the reduction of A_{new}, i.e. no extra lookups are needed for the latter. In the last round we reduce A_{new} after adding the feedforward (requiring a carry of \{0, \ldots, 7\} which is fine).

(A ⋙ 2) \oplus (A ⋙ 13) \oplus (A ⋙ 22) is equivalent to (A ⋙ 2) \oplus (A ⋙ 13) \oplus (A ⋘ 10):

Then, using 4 more \mathtt{spread} lookups we obtain the result as the even bits of a linear combination of the pieces:

\begin{array}{rcccccccl} & (a &||& d &||& c &||& b) & \oplus \ & (b &||& a &||& d &||& c) & \oplus \ & (c &||& b &||& a &||& d) & \ &&&&\Downarrow \ R' = & 4^{30} a &+& 4^{20} d &+& 4^{11} c &+& b;&+ \ & 4^{21} b &+& 4^{19} a &+& 4^{ 9} d &+& c;&+ \ & 4^{23} c &+& 4^{12} b &+& 4^{10} a &+& d;& \end{array}

That is, we witness the compressed even bits R^{even}_i and the compressed odd bits R^{odd}_i, and constrain

R' = \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1)

where \{R^{even}_i\}_{i=0..1} is the \Sigma_0 function output.

Σ_1 function

\Sigma_1(E) can be done in 6 lookups.

To achieve this we first split E into pieces (a, b, c, d), of lengths (6, 5, 14, 7) bits respectively counting from the little end. At the same time we obtain the spread forms of these pieces. This can all be done in two PLONK rows, because the 7 and $14$-bit pieces can be handled using \mathtt{spread} lookups, the $5$-bit piece can be split into 3 and $2$-bit subpieces, and the $6$-bit piece can be split into $2 * 3$-bit subpieces. The four small pieces can be range-checked by polynomial constraints in parallel with the two lookups, two small pieces in each row. The spread forms of these small pieces are found by interpolation.

Note that the splitting into pieces can be combined with the reduction of E_{new}, i.e. no extra lookups are needed for the latter. In the last round we reduce E_{new} after adding the feedforward (requiring a carry of \{0, \ldots, 6\} which is fine).

(E ⋙ 6) \oplus (E ⋙ 11) \oplus (E ⋙ 25) is equivalent to (E ⋙ 6) \oplus (E ⋙ 11) \oplus (E ⋘ 7).

Then, using 4 more \mathtt{spread} lookups we obtain the result as the even bits of a linear combination of the pieces, in the same way we did for \Sigma_0:

\begin{array}{rcccccccl} & (a &||& d &||& c &||& b) & \oplus \ & (b &||& a &||& d &||& c) & \oplus \ & (c &||& b &||& a &||& d) & \ &&&&\Downarrow \ R' = & 4^{26} a &+& 4^{19} d &+& 4^{ 5} c &+& b;&+ \ & 4^{27} b &+& 4^{21} a &+& 4^{14} d &+& c;&+ \ & 4^{18} c &+& 4^{13} b &+& 4^{ 7} a &+& d;& \end{array}

That is, we witness the compressed even bits R^{even}_i and the compressed odd bits R^{odd}_i, and constrain

R' = \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1)

where \{R^{even}_i\}_{i=0..1} is the \Sigma_1 function output.

Block decomposition

For each block M \in \{0,1\}^{512} of the padded message, 64 words of 32 bits each are constructed as follows:

• The first 16 are obtained by splitting M into $32$-bit blocks M = W_0 || W_1 || \cdots || W_{14} || W_{15};
• The remaining 48 words are constructed using the formula: W_i = \sigma_1(W_{i-2}) \boxplus W_{i-7} \boxplus \sigma_0(W_{i-15}) \boxplus W_{i-16}, for i = 17, \ldots, 64.

Note: $0$-based numbering is used for the W word indices.

\begin{array}{ccc} \sigma_0(X) &=& (X ⋙ 7) \oplus (X ⋙ 18) \oplus (X ≫ 3) \ \sigma_1(X) &=& (X ⋙ 17) \oplus (X ⋙ 19) \oplus (X ≫ 10) \ \end{array}

Note: ≫ is a right-shift, not a rotation.

σ_0 function

(X ⋙ 7) \oplus (X ⋙ 18) \oplus (X ≫ 3) is equivalent to (X ⋙ 7) \oplus (X ⋘ 14) \oplus (X ≫ 3).

As above but with pieces (a, b, c, d) of lengths (3, 4, 11, 14) counting from the little end. Split b into two $2$-bit subpieces.

\begin{array}{rcccccccl} & (0^{[3]} &||& d &||& c &||& b) & \oplus \ & (;;;b &||& a &||& d &||& c) & \oplus \ & (;;;c &||& b &||& a &||& d) & \ &&&&\Downarrow \ R' = & & & 4^{15} d &+& 4^{ 4} c &+& b;&+ \ & 4^{28} b &+& 4^{25} a &+& 4^{11} d &+& c;&+ \ & 4^{21} c &+& 4^{17} b &+& 4^{14} a &+& d;& \end{array}

σ_1 function

(X ⋙ 17) \oplus (X ⋙ 19) \oplus (X ≫ 10) is equivalent to (X ⋘ 15) \oplus (X ⋘ 13) \oplus (X ≫ 10).

TODO: this diagram doesn't match the expression on the right. This is just for consistency with the other diagrams.

As above but with pieces (a, b, c, d) of lengths (10, 7, 2, 13) counting from the little end. Split b into $(3, 2, 2)$-bit subpieces.

\begin{array}{rcccccccl} & (0^{[10]}&||& d &||& c &||& b) & \oplus \ & (;;;b &||& a &||& d &||& c) & \oplus \ & (;;;c &||& b &||& a &||& d) & \ &&&&\Downarrow \ R' = & & & 4^{ 9} d &+& 4^{ 7} c &+& b;&+ \ & 4^{25} b &+& 4^{15} a &+& 4^{ 2} d &+& c;&+ \ & 4^{30} c &+& 4^{23} b &+& 4^{13} a &+& d;& \end{array}

Message scheduling

We apply \sigma_0 to W_{1..48}, and \sigma_1 to W_{14..61}. In order to avoid redundant applications of \mathtt{spread}, we can merge the splitting into pieces for \sigma_0 and \sigma_1 in the case of W_{14..48}. Merging the piece lengths (3, 4, 11, 14) and (10, 7, 2, 13) gives pieces of lengths (3, 4, 3, 7, 1, 1, 13).

If we can do the merged split in 3 rows (as opposed to a total of 4 rows when splitting for \sigma_0 and \sigma_1 separately), we save 35 rows.

These might even be doable in 2 rows; not sure. [name=Daira]

We can merge the reduction mod 2^{32} of W_{16..61} into their splitting when they are used to compute subsequent words, similarly to what we did for A and E in the round function.

We will still need to reduce W_{62..63} since they are not split. (Technically we could leave them unreduced since they will be reduced later when they are used to compute A_{new} and E_{new} -- but that would require handling a carry of up to 10 rather than 6, so it's not worth the complexity.)

The resulting message schedule cost is:

• 2 rows to constrain W_0 to 32 bits
  • This is technically optional, but let's do it for robustness, since the rest of the input is constrained for free.
• 13*2 rows to split W_{1..13} into $(3, 4, 11, 14)$-bit pieces
• 35*3 rows to split W_{14..48} into $(3, 4, 3, 7, 1, 1, 13)$-bit pieces (merged with a reduction for W_{16..48})
• 13*2 rows to split W_{49..61} into $(10, 7, 2, 13)$-bit pieces (merged with a reduction)
• 4*48 rows to extract the results of \sigma_0 for W_{1..48}
• 4*48 rows to extract the results of \sigma_1 for W_{14..61}
• 2*2 rows to reduce W_{62..63}
• = 547 rows.

Overall cost

For each round:

• 8 rows for Ch
• 4 rows for Maj
• 6 rows for \Sigma_0
• 6 rows for \Sigma_1
• reduce_6 and reduce_7 are always free
• = 24 per round

This gives 24*64 = 1792 rows for all of "step 3", to which we need to add:

• 547 rows for message scheduling
• 2*8 rows for 8 reductions mod 2^{32} in "step 4"

giving a total of 2099 rows.

Tables

We only require one table \mathtt{spread}, with 2^{16} rows and 3 columns. We need a tag column to allow selecting $(7, 10, 11, 13, 14)$-bit subsets of the table for \Sigma_{0..1} and \sigma_{0..1}.

spread table

row	tag	table (16b)	spread (32b)
0	0	0000000000000000	00000000000000000000000000000000
1	0	0000000000000001	00000000000000000000000000000001
2	0	0000000000000010	00000000000000000000000000000100
3	0	0000000000000011	00000000000000000000000000000101
...	0	...	...
2^{7} - 1	0	0000000001111111	00000000000000000001010101010101
2^{7}	1	0000000010000000	00000000000000000100000000000000
...	1	...	...
2^{10} - 1	1	0000001111111111	00000000000001010101010101010101
...	2	...	...
2^{11} - 1	2	0000011111111111	00000000010101010101010101010101
...	3	...	...
2^{13} - 1	3	0001111111111111	00000001010101010101010101010101
...	4	...	...
2^{14} - 1	4	0011111111111111	00000101010101010101010101010101
...	5	...	...
2^{16} - 1	5	1111111111111111	01010101010101010101010101010101

For example, to do an $11$-bit \mathtt{spread} lookup, we polynomial-constrain the tag to be in \{0, 1, 2\}. For the most common case of a $16$-bit lookup, we don't need to constrain the tag. Note that we can fill any unused rows beyond 2^{16} with a duplicate entry, e.g. all-zeroes.

Gates

Choice gate

Input from previous operations:

• E', F', G', 64-bit spread forms of 32-bit words E, F, G, assumed to be constrained by previous operations
  • in practice, we'll have the spread forms of E', F', G' after they've been decomposed into 16-bit subpieces
• evens is defined as \mathtt{spread}(2^{32} - 1)
  • evens_0 = evens_1 = \mathtt{spread}(2^{16} - 1)

s_neg	s_ch	a_0	a_1	a_2	a_3	a_4
0	0	{0,1,2,3,4,5}	P_0^{even}	\texttt{spread}(P_0^{even})	\mathtt{spread}(E^{lo})	\mathtt{spread}(E^{hi})
0	1	{0,1,2,3,4,5}	P_0^{odd}	\texttt{spread}(P_0^{odd})	\texttt{spread}(P_1^{odd})
0	0	{0,1,2,3,4,5}	P_1^{even}	\texttt{spread}(P_1^{even})	\mathtt{spread}(F^{lo})	\mathtt{spread}(F^{hi})
0	0	{0,1,2,3,4,5}	P_1^{odd}	\texttt{spread}(P_1^{odd})	evens_0	evens_1
1	0	{0,1,2,3,4,5}	Q_0^{even}	\texttt{spread}(Q_0^{even})	\mathtt{spread}(E^{lo})	\mathtt{spread}(E^{hi})
0	0	{0,1,2,3,4,5}	Q_0^{odd}	\texttt{spread}(Q_0^{odd})	evens_0 - \mathtt{spread}(E^{lo})	evens_1 - \mathtt{spread}(E^{hi})
0	1	{0,1,2,3,4,5}	Q_1^{even}	\texttt{spread}(Q_1^{even})	\texttt{spread}(Q_1^{odd})
0	0	{0,1,2,3,4,5}	Q_1^{odd}	\texttt{spread}(Q_1^{odd})	\mathtt{spread}(G^{lo})	\mathtt{spread}(G^{hi})

Constraints:

• s_ch (choice): LHS - RHS = 0
  • LHS = a_3 \omega^{-1} + a_3 \omega + 2^{32}(a_4 \omega^{-1} + a_4 \omega)
  • RHS = a_2 \omega^{-1} + 2* a_2 + 2^{32}(a_2 \omega + 2* a_3)
• s_neg (negation):
  • a_3\omega^{-1} - a_3 - a_3\omega = 0
  • a_4\omega^{-1} - a_4 - a_4\omega = 0
• \mathtt{spread} lookup on (a_0, a_1, a_2)
• permutation between (a_2, a_3)

Output: Ch(E, F, G) = P^{odd} + Q^{odd} = (P_0^{odd} + Q_0^{odd}) + 2^{16} (P_1^{odd} + Q_1^{odd})

Majority gate

Input from previous operations:

• A', B', C', 64-bit spread forms of 32-bit words A, B, C, assumed to be constrained by previous operations
  • in practice, we'll have the spread forms of A', B', C' after they've been decomposed into $16$-bit subpieces

s_maj	a_0	a_1	a_2	a_3	a_4	a_5
0	{0,1,2,3,4,5}	M_0^{even}	\texttt{spread}(M_0^{even})		\mathtt{spread}(A^{lo})	\mathtt{spread}(A^{hi})
1	{0,1,2,3,4,5}	M_0^{odd}	\texttt{spread}(M_0^{odd})	\texttt{spread}(M_1^{odd})	\mathtt{spread}(B^{lo})	\mathtt{spread}(B^{hi})
0	{0,1,2,3,4,5}	M_1^{even}	\texttt{spread}(M_1^{even})		\mathtt{spread}(C^{lo})	\mathtt{spread}(C^{hi})
0	{0,1,2,3,4,5}	M_1^{odd}	\texttt{spread}(M_1^{odd})

Constraints:

• s_maj (majority): LHS - RHS = 0
  • LHS = \mathtt{spread}(M^{even}_0) + 2 \cdot \mathtt{spread}(M^{odd}_0) + 2^{32} \cdot \mathtt{spread}(M^{even}_1) + 2^{33} \cdot \mathtt{spread}(M^{odd}_1)
  • RHS = A' + B' + C'
• \mathtt{spread} lookup on (a_0, a_1, a_2)
• permutation between (a_2, a_3)

Output: Maj(A,B,C) = M^{odd} = M_0^{odd} + 2^{16} M_1^{odd}

Σ_0 gate

A is a 32-bit word split into $(2,11,9,10)$-bit chunks, starting from the little end. We refer to these chunks as (a(2), b(11), c(9), d(10)) respectively, and further split c(9) into three 3-bit chunks c(9)^{lo}, c(9)^{mid}, c(9)^{hi}. We witness the spread versions of the small chunks.

\begin{array}{ccc} \Sigma_0(A) &=& (A ⋙ 2) \oplus (A ⋙ 13) \oplus (A ⋙ 22) \ &=& (A ⋙ 2) \oplus (A ⋙ 13) \oplus (A ⋘ 10) \end{array}

s_upp_sigma_0	a_0	a_1	a_2	a_3	a_4	a_5	a_6
0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	c(9)^{lo}	\texttt{spread}(c(9)^{lo})	c(9)^{mid}	\texttt{spread}(c(9)^{mid})
1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(d(10))	\texttt{spread}(b(11))	c(9)
0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	a(2)	\texttt{spread}(a(2))	c(9)^{hi}	\texttt{spread}(c(9)^{hi})
0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})

Constraints:

• s_upp_sigma_0 (\Sigma_0 constraint): LHS - RHS + tag + decompose = 0

\begin{array}{ccc} tag &=& constrain_1(a_0\omega^{-1}) + constrain_2(a_0\omega) \ decompose &=& a(2) + 2^2 b(11) + 2^{13} c(9)^{lo} + 2^{16} c(9)^{mid} + 2^{19} c(9)^{hi} + 2^{22} d(10) - A\ LHS &=& \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1) \end{array} \begin{array}{rcccccccccl} RHS = & 4^{30} \texttt{spread}(a(2)) &+& 4^{20} \texttt{spread}(d(10)) &+& 4^{17} \texttt{spread}(c(9)^{hi}) &+& 4^{14} \texttt{spread}(c(9)^{mid}) &+& 4^{11} \texttt{spread}(c(9)^{lo}) &+& \texttt{spread}(b(11));&+ \ & 4^{21} \texttt{spread}(b(11)) &+& 4^{19} \texttt{spread}(a(2)) &+& 4^{9} \texttt{spread}(d(10)) &+& 4^{6} \texttt{spread}(c(9)^{hi}) &+& 4^{3} \texttt{spread}(c(9)^{mid}) &+& \texttt{spread}(c(9)^{lo}) ;&+ \ & 4^{29} \texttt{spread}(c(9)^{hi}) &+& 4^{26} \texttt{spread}(c(9)^{mid}) &+& 4^{23} \texttt{spread}(c(9)^{lo}) &+& 4^{12} \texttt{spread}(b(11)) &+& 4^{10} \texttt{spread}(a(2)) &+& \texttt{spread}(d(10));& \end{array}

• \mathtt{spread} lookup on a_0, a_1, a_2
• 2-bit range check and 2-bit spread check on a(2)
• 3-bit range check and 3-bit spread check on c(9)^{lo}, c(9)^{mid}, c(9)^{hi}

(see section Helper gates)

Output: \Sigma_0(A) = R^{even} = R_0^{even} + 2^{16} R_1^{even}

Σ_1 gate

E is a 32-bit word split into $(6,5,14,7)$-bit chunks, starting from the little end. We refer to these chunks as (a(6), b(5), c(14), d(7)) respectively, and further split a(6) into two 3-bit chunks a(6)^{lo}, a(6)^{hi} and b into (2,3)-bit chunks b(5)^{lo}, b(5)^{hi}. We witness the spread versions of the small chunks.

\begin{array}{ccc} \Sigma_1(E) &=& (E ⋙ 6) \oplus (E ⋙ 11) \oplus (E ⋙ 25) \ &=& (E ⋙ 6) \oplus (E ⋙ 11) \oplus (E ⋘ 7) \end{array}

s_upp_sigma_1	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7
0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	b(5)^{lo}	\texttt{spread}(b(5)^{lo})	b(5)^{hi}	\texttt{spread}(b(5)^{hi})	b(5)
1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(d(7))	\texttt{spread}(c(14))
0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	a(6)^{lo}	\texttt{spread}(a(6)^{lo})	a(6)^{hi}	\texttt{spread}(a(6)^{hi})	a(6)
0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})

Constraints:

• s_upp_sigma_1 (\Sigma_1 constraint): LHS - RHS + tag + decompose = 0

\begin{array}{ccc} tag &=& a_0\omega^{-1} + constrain_4(a_0\omega) \ decompose &=& a(6)^{lo} + 2^3 a(6)^{hi} + 2^6 b(5)^{lo} + 2^8 b(5)^{hi} + 2^{11} c(14) + 2^{25} d(7) - E \ LHS &=& \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1) \end{array} \begin{array}{rcccccccccl} RHS = & 4^{29} \texttt{spread}(a(6)^{hi}) &+& 4^{26} \texttt{spread}(a(6)^{lo}) &+& 4^{19} \texttt{spread}(d(7)) &+& 4^{ 5} \texttt{spread}(c(14)) &+& 4^{2} \texttt{spread}(b(5)^{hi}) &+& \texttt{spread}(b(5)^{lo});&+ \ & 4^{29} \texttt{spread}(b(5)^{hi}) &+& 4^{27} \texttt{spread}(b(5)^{lo}) &+& 4^{24} \texttt{spread}(a(6)^{hi}) &+& 4^{21} \texttt{spread}(a(6)^{lo}) &+& 4^{14} \texttt{spread}(d(7)) &+& \texttt{spread}(c(14));&+ \ & 4^{18} \texttt{spread}(c(14)) &+& 4^{15} \texttt{spread}(b(5)^{hi}) &+& 4^{13} \texttt{spread}(b(5)^{lo}) &+& 4^{10} \texttt{spread}(a(6)^{hi}) &+& 4^{7} \texttt{spread}(a(6)^{lo}) &+& \texttt{spread}(d(7));& \end{array}

• \mathtt{spread} lookup on a_0, a_1, a_2
• 2-bit range check and 2-bit spread check on b(5)^{lo}
• 3-bit range check and 3-bit spread check on a(6)^{lo}, a(6)^{hi}, b(4)^{hi}

(see section Helper gates)

Output: \Sigma_1(E) = R^{even} = R_0^{even} + 2^{16} R_1^{even}

σ_0 gate

v1

v1 of the \sigma_0 gate takes in a word that's split into $(3, 4, 11, 14)$-bit chunks (already constrained by message scheduling). We refer to these chunks respectively as (a(3), b(4), c(11), d(14)). b(4 is further split into two 2-bit chunks b(4)^{lo},b(4)^{hi}. We witness the spread versions of the small chunks. We already have \texttt{spread}(c(11)) and \texttt{spread}(d(14)) from the message scheduling.

(X ⋙ 7) \oplus (X ⋙ 18) \oplus (X ≫ 3) is equivalent to (X ⋙ 7) \oplus (X ⋘ 14) \oplus (X ≫ 3).

s_low_sigma_0	a_0	a_1	a_2	a_3	a_4	a_5	a_6
0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	b(4)^{lo}	\texttt{spread}(b(4)^{lo})	b(4)^{hi}	\texttt{spread}(b(4)^{hi})
1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(c)	\texttt{spread}(d)	b(4)
0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	0	0	a	\texttt{spread}(a)
0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})

Constraints:

• s_low_sigma_0 (\sigma_0 v1 constraint): LHS - RHS = 0

\begin{array}{ccc} LHS &=& \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1) \end{array} \begin{array}{rccccccccl} RHS = & & & 4^{15} d(14) &+& 4^{ 4} c(11) &+& 4^2 b(4)^{hi} &+& b(4)^{lo};&+ \ & 4^{30} b(4)^{hi} &+& 4^{28} b(4)^{lo} &+& 4^{25} a(3) &+& 4^{11} d(14) &+& c(11);&+ \ & 4^{21} c(11) &+& 4^{19} b(4)^{hi} &+& 4^{17} b(4)^{lo} &+& 4^{14} a(3) &+& d(14);& \end{array}

• check that b was properly split into subsections for 4-bit pieces.
  • W^{b(4)lo} + 2^2 W^{b(4)hi} - W = 0
• 2-bit range check and 2-bit spread check on b(4)^{lo}, b(4)^{hi}
• 3-bit range check and 3-bit spread check on a(3)

v2

v2 of the \sigma_0 gate takes in a word that's split into $(3, 4, 3, 7, 1, 1, 13)$-bit chunks (already constrained by message scheduling). We refer to these chunks respectively as (a(3), b(4), c(3), d(7), e(1), f(1), g(13)). We already have \mathtt{spread}(d(7)), \mathtt{spread}(g(13)) from the message scheduling. The 1-bit e(1), f(1) remain unchanged by the spread operation and can be used directly. We further split b(4) into two 2-bit chunks b(4)^{lo}, b(4)^{hi}. We witness the spread versions of the small chunks.

(X ⋙ 7) \oplus (X ⋙ 18) \oplus (X ≫ 3) is equivalent to (X ⋙ 7) \oplus (X ⋘ 14) \oplus (X ≫ 3).

s_low_sigma_0_v2	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7
0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	b(4)^{lo}	\texttt{spread}(b(4)^{lo})	b(4)^{hi}	\texttt{spread}(b(4)^{hi})
1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(d(7))	\texttt{spread}(g(13))	b(4)	e(1)
0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	a(3)	\texttt{spread}(a(3))	c(3)	\texttt{spread}(c(3))	f(1)
0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})

Constraints:

• s_low_sigma_0_v2 (\sigma_0 v2 constraint): LHS - RHS = 0

\begin{array}{ccc} LHS &=& \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1) \end{array} \begin{array}{rcccccccccccl} RHS = & & & 4^{16} g(13) &+& 4^{15} f(1) &+& 4^{ 14} e(1) &+& 4^{ 7} d(7) &+& 4^{ 4} c(3) &+& 4^2 b(4)^{hi} &+& b(4)^{lo};&+ \ & 4^{30} b(4)^{hi} &+& 4^{28} b(4)^{lo} &+& 4^{25} a(3) &+& 4^{12} g(13) &+& 4^{11} f(1) &+& 4^{10} e(1) &+& 4^{3} d(7) &+& c(3);&+ \ & 4^{31} e(1) &+& 4^{24} d(7) &+& 4^{21} c(3) &+& 4^{19} b(4)^{hi} &+& 4^{17} b(4)^{lo} &+& 4^{14} a(3) &+& 4^{1} g(13) &+& f(1);& \end{array}

• check that b was properly split into subsections for 4-bit pieces.
  • W^{b(4)lo} + 2^2 W^{b(4)hi} - W = 0
• 2-bit range check and 2-bit spread check on b(4)^{lo}, b(4)^{hi}
• 3-bit range check and 3-bit spread check on a(3), c(3)

σ_1 gate

v1

v1 of the \sigma_1 gate takes in a word that's split into $(10, 7, 2, 13)$-bit chunks (already constrained by message scheduling). We refer to these chunks respectively as (a(10), b(7), c(2), d(13)). b(7) is further split into $(2, 2, 3)$-bit chunks b(7)^{lo}, b(7)^{mid}, b(7)^{hi}. We witness the spread versions of the small chunks. We already have \texttt{spread}(a(10)) and \texttt{spread}(d(13)) from the message scheduling.

(X ⋙ 17) \oplus (X ⋙ 19) \oplus (X ≫ 10) is equivalent to (X ⋘ 15) \oplus (X ⋘ 13) \oplus (X ≫ 10).

s_low_sigma_1	a_0	a_1	a_2	a_3	a_4	a_5	a_6
0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	b(7)^{lo}	\texttt{spread}(b(7)^{lo})	b(7)^{mid}	\texttt{spread}(b(7)^{mid})
1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(a(10))	\texttt{spread}(d(13))	b(7)
0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	c(2)	\texttt{spread}(c(2))	b(7)^{hi}	\texttt{spread}(b(7)^{hi})
0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})

Constraints:

• s_low_sigma_1 (\sigma_1 v1 constraint): LHS - RHS = 0 \begin{array}{ccc} LHS &=& \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1) \end{array} \begin{array}{rcccccccccl} RHS = & & & 4^{ 9} d(13) &+& 4^{ 7} c(2) &+& 4^{4} b(7)^{hi} &+& 4^{2} b(7)^{mid} &+& b(7)^{lo};&+ \ & 4^{29} b(7)^{hi} &+& 4^{27} b(7)^{mid} &+& 4^{25} b(7)^{lo} &+& 4^{15} a(10) &+& 4^{ 2} d(13) &+& c(2);&+ \ & 4^{30} c(2) &+& 4^{27} b(7)^{hi} &+& 4^{25} b(7)^{mid} &+& 4^{23} b(7)^{lo} &+& 4^{13} a(10) &+& d(13);& \end{array}

• check that b was properly split into subsections for 7-bit pieces.

  • W^{b(7)lo} + 2^2 W^{b(7)mid} + 2^4 W^{b(7)hi} - W = 0

• 2-bit range check and 2-bit spread check on b(7)^{lo}, b(7)^{mid}, c(2)

• 3-bit range check and 3-bit spread check on b(7)^{hi}

v2

v2 of the \sigma_1 gate takes in a word that's split into $(3, 4, 3, 7, 1, 1, 13)$-bit chunks (already constrained by message scheduling). We refer to these chunks respectively as (a(3), b(4), c(3), d(7), e(1), f(1), g(13)). We already have \mathtt{spread}(d(7)), \mathtt{spread}(g(13)) from the message scheduling. The 1-bit e(1), f(1) remain unchanged by the spread operation and can be used directly. We further split b(4) into two 2-bit chunks b(4)^{lo}, b(4)^{hi}. We witness the spread versions of the small chunks.

(X ⋙ 17) \oplus (X ⋙ 19) \oplus (X ≫ 10) is equivalent to (X ⋘ 15) \oplus (X ⋘ 13) \oplus (X ≫ 10).

s_low_sigma_1_v2	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7
0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	b(4)^{lo}	\texttt{spread}(b(4)^{lo})	b(4)^{hi}	\texttt{spread}(b(4)^{hi})
1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(d(7))	\texttt{spread}(g(13))	b(4)	e(1)
0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	a(3)	\texttt{spread}(a(3))	c(3)	\texttt{spread}(c(3))	f(1)
0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})

Constraints:

• s_low_sigma_1_v2 (\sigma_1 v2 constraint): LHS - RHS = 0

\begin{array}{ccc} LHS &=& \mathtt{spread}(R^{even}_0) + 2 \cdot \mathtt{spread}(R^{odd}_0) + 2^{32} \cdot \mathtt{spread}(R^{even}_1) + 2^{33} \cdot \mathtt{spread}(R^{odd}_1) \end{array} \begin{array}{rccccccccccccl} RHS = & &&&& & & 4^{ 9} g(13) &+& 4^{ 8} f(1) &+& 4^{ 7} e(1) &+& d(7);&+ \ & 4^{25} d(7) &+& 4^{22} c(3) &+& 4^{20} b(4)^{hi} &+& 4^{18} b(4)^{lo} &+& 4^{15} a &+& 4^{ 2} g(13) &+& 4^{1}f(1) &+& e(1);&+ \ & 4^{31} f(1) &+& 4^{30} e(1) &+& 4^{23} d(7) &+& 4^{20} c(3) &+& 4^{18} b(4)^{hi} &+& 4^{16} b(4)^{lo} &+& 4^{13} a &+& g(13);& \end{array}

• check that b was properly split into subsections for 4-bit pieces.
  • W^{b(4)lo} + 2^2 W^{b(4)hi} - W = 0
• 2-bit range check and 2-bit spread check on b(4)^{lo}, b(4)^{hi}
• 3-bit range check and 3-bit spread check on a(3), c(3)

Helper gates

Small range constraints

Let constrain_n(x) = \prod_{i=0}^n (x-i). Constraining this expression to equal zero enforces that x is in [0..n].

2-bit range check

(a - 3)(a - 2)(a - 1)(a) = 0

sr2	a_0
1	a

2-bit spread

l_1(a) + 4*l_2(a) + 5*l_3(a) - a' = 0

ss2	a_0	a_1
1	a	a'

with interpolation polynomials:

• l_0(a) = \frac{(a - 3)(a - 2)(a - 1)}{(-3)(-2)(-1)} (\mathtt{spread}(00) = 0000)
• l_1(a) = \frac{(a - 3)(a - 2)(a)}{(-2)(-1)(1)} (\mathtt{spread}(01) = 0001)
• l_2(a) = \frac{(a - 3)(a - 1)(a)}{(-1)(1)(2)} (\mathtt{spread}(10) = 0100)
• l_3(a) = \frac{(a - 2)(a - 1)(a)}{(1)(2)(3)} (\mathtt{spread}(11) = 0101)

3-bit range check

(a - 7)(a - 6)(a - 5)(a - 4)(a - 3)(a - 2)(a - 1)(a) = 0

sr3	a_0
1	a

3-bit spread

l_1(a) + 4*l_2(a) + 5*l_3(a) + 16*l_4(a) + 17*l_5(a) + 20*l_6(a) + 21*l_7(a) - a' = 0

ss3	a_0	a_1
1	a	a'

with interpolation polynomials:

• l_0(a) = \frac{(a - 7)(a - 6)(a - 5)(a - 4)(a - 3)(a - 2)(a - 1)}{(-7)(-6)(-5)(-4)(-3)(-2)(-1)} (\mathtt{spread}(000) = 000000)
• l_1(a) = \frac{(a - 7)(a - 6)(a - 5)(a - 4)(a - 3)(a - 2)(a)}{(-6)(-5)(-4)(-3)(-2)(-1)(1)} (\mathtt{spread}(001) = 000001)
• l_2(a) = \frac{(a - 7)(a - 6)(a - 5)(a - 4)(a - 3)(a - 1)(a)}{(-5)(-4)(-3)(-2)(-1)(1)(2)} (\mathtt{spread}(010) = 000100)
• l_3(a) = \frac{(a - 7)(a - 6)(a - 5)(a - 3)(a - 2)(a - 1)(a)}{(-4)(-3)(-2)(-1)(1)(2)(3)} (\mathtt{spread}(011) = 000101)
• l_4(a) = \frac{(a - 7)(a - 6)(a - 5)(a - 3)(a - 2)(a - 1)(a)}{(-3)(-2)(-1)(1)(2)(3)(4)} (\mathtt{spread}(100) = 010000)
• l_5(a) = \frac{(a - 7)(a - 6)(a - 4)(a - 3)(a - 2)(a - 1)(a)}{(-2)(-1)(1)(2)(3)(4)(5)} (\mathtt{spread}(101) = 010001)
• l_6(a) = \frac{(a - 7)(a - 5)(a - 4)(a - 3)(a - 2)(a - 1)(a)}{(-1)(1)(2)(3)(4)(5)(6)} (\mathtt{spread}(110) = 010100)
• l_7(a) = \frac{(a - 6)(a - 5)(a - 4)(a - 3)(a - 2)(a - 1)(a)}{(1)(2)(3)(4)(5)(6)(7)} (\mathtt{spread}(111) = 010101)

reduce_6 gate

Addition \pmod{2^{32}} of 6 elements

Input:

• E
• \{e_i^{lo}, e_i^{hi}\}_{i=0}^5
• carry

Check: E = e_0 + e_1 + e_2 + e_3 + e_4 + e_5 \pmod{32}

Assume inputs are constrained to 16 bits.

• Addition gate (sa):
  • a_0 + a_1 + a_2 + a_3 + a_4 + a_5 + a_6 - a_7 = 0
• Carry gate (sc):
  • 2^{16} a_6 \omega^{-1} + a_6 + [(a_6 - 5)(a_6 - 4)(a_6 -3)(a_6 - 2)(a_6 - 1)(a_6)] = 0

sa	sc	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7
1	0	e_0^{lo}	e_1^{lo}	e_2^{lo}	e_3^{lo}	e_4^{lo}	e_5^{lo}	-carry*2^{16}	E^{lo}
1	1	e_0^{hi}	e_1^{hi}	e_2^{hi}	e_3^{hi}	e_4^{hi}	e_5^{hi}	carry	E^{hi}

Assume inputs are constrained to 16 bits.

• Addition gate (sa):
  • a_0 \omega^{-1} + a_1 \omega^{-1} + a_2 \omega^{-1} + a_0 + a_1 + a_2 + a_3 \omega^{-1} - a_3 = 0
• Carry gate (sc):
  • 2^{16} a_3 \omega + a_3 \omega^{-1} = 0

sa	sc	a_0	a_1	a_2	a_3
0	0	e_0^{lo}	e_1^{lo}	e_2^{lo}	-carry*2^{16}
1	1	e_3^{lo}	e_4^{lo}	e_5^{lo}	E^{lo}
0	0	e_0^{hi}	e_1^{hi}	e_2^{hi}	carry
1	0	e_3^{hi}	e_4^{hi}	e_5^{hi}	E^{hi}

reduce_7 gate

Addition \pmod{2^{32}} of 7 elements

Input:

• E
• \{e_i^{lo}, e_i^{hi}\}_{i=0}^6
• carry

Check: E = e_0 + e_1 + e_2 + e_3 + e_4 + e_5 + e_6 \pmod{32}

Assume inputs are constrained to 16 bits.

• Addition gate (sa):
  • a_0 + a_1 + a_2 + a_3 + a_4 + a_5 + a_6 + a_7 - a_8 = 0
• Carry gate (sc):
  • 2^{16} a_7 \omega^{-1} + a_7 + [(a_7 - 6)(a_7 - 5)(a_7 - 4)(a_7 -3)(a_7 - 2)(a_7 - 1)(a_7)] = 0

sa	sc	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7	a_8
1	0	e_0^{lo}	e_1^{lo}	e_2^{lo}	e_3^{lo}	e_4^{lo}	e_5^{lo}	e_6^{lo}	-carry*2^{16}	E^{lo}
1	1	e_0^{hi}	e_1^{hi}	e_2^{hi}	e_3^{hi}	e_4^{hi}	e_5^{hi}	e_6^{hi}	carry	E^{hi}

Message scheduling region

For each block M \in \{0,1\}^{512} of the padded message, 64 words of 32 bits each are constructed as follows:

• the first 16 are obtained by splitting M into $32$-bit blocks M = W_0 || W_1 || \cdots || W_{14} || W_{15};
• the remaining 48 words are constructed using the formula: W_i = \sigma_1(W_{i-2}) \boxplus W_{i-7} \boxplus \sigma_0(W_{i-15}) \boxplus W_{i-16}, for i = 16, \ldots, 63.

sw	sd0	sd1	sd2	sd3	ss0	ss0_v2	ss1	ss1_v2	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7	a_8	a_9
0	1	0	0	0	0	0	0	0	{0,1,2,3,4,5}	W_{0}^{lo}	\texttt{spread}(W_{0}^{lo})	W_{0}^{lo}	W_{0}^{hi}	W_{0}	\sigma_0(W_1)^{lo}	\sigma_1(W_{14})^{lo}	W_{9}^{lo}
1	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	W_{0}^{hi}	\texttt{spread}(W_{0}^{hi})			W_{16}	\sigma_0(W_1)^{hi}	\sigma_1(W_{14})^{hi}	W_{9}^{hi}	carry_{16}
0	1	1	0	0	0	0	0	0	{0,1,2,3,4}	W_{1}^{d(14)}	\texttt{spread}(W_{1}^{d(14)})	W_{1}^{lo}	W_{1}^{hi}	W_{1}	\sigma_0(W_2)^{lo}	\sigma_1(W_{15})^{lo}	W_{10}^{lo}
1	0	0	0	0	0	0	0	0	{0,1,2}	W_{1}^{c(11)}	\texttt{spread}(W_{1}^{c(11)})	W_{1}^{a(3)}	W_{1}^{b(4)}	W_{17}	\sigma_0(W_2)^{hi}	\sigma_1(W_{15})^{hi}	W_{10}^{hi}	carry_{17}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	W_{1}^{b(4)lo}	\texttt{spread}(W_{1}^{b(4)lo})	W_{1}^{b(4)hi}	\texttt{spread}(W_{1}^{b(4)hi})
0	0	0	0	0	1	0	0	0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(W_{1}^{c(11)})	\texttt{spread}(W_{1}^{d(14)})	W_{1}^{b(4)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_1^{even})	0	0	W_{1}^{a(3)}	\texttt{spread}(W_{1}^{a(3)})
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{odd})	\sigma_0 v1 R_0	\sigma_0 v1 R_1	\sigma_0 v1 R_0^{even}	\sigma_0 v1 R_0^{odd}
..	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...
0	0	0	0	0	0	0	0	0	{0,1,2,3}	W_{14}^{g(13)}	\texttt{spread}(W_{14}^{g(13)})	W_{14}^{a(3)}	W_{14}^{c(3)}
0	1	0	1	0	0	0	0	0	0	W_{14}^{d(7)}	\texttt{spread}(W_{14}^{d(7)})	W_{14}^{lo}	W_{14}^{hi}	W_{14}	\sigma_0(W_{15})^{lo}	\sigma_1(W_{28})^{lo}	W_{23}^{lo}
1	0	0	0	0	0	0	0	0	0	W_{14}^{b(4)}	\texttt{spread}(W_{14}^{b(4)})	W_{14}^{e(1)}	W_{14}^{f(1)}	W_{30}	\sigma_0(W_{15})^{hi}	\sigma_1(W_{28})^{hi}	W_{23}^{hi}	carry_{30}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	W_{14}^{b(4)lo}	\texttt{spread}(W_{14}^{b(4)lo})	W_{14}^{b(4) hi}	\texttt{spread}(W_{14}^{b(4)hi})
0	0	0	0	0	0	1	0	0	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(W_{14}^{d(7)})	\texttt{spread}(W_{14}^{g(13)})	W_{1}^{b(14)}	W_{14}^{e(1)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	W_{14}^{a(3)}	\texttt{spread}(W_{14}^{a(3)})	W_{14}^{c(3)}	\texttt{spread}(W_{14}^{c(3)})	W_{14}^{f(1)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})	\sigma_0 v2 R_0	\sigma_0 v2 R_1	\sigma_0 v2 R_0^{even}	\sigma_0 v2 R_0^{odd}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	W_{14}^{b(4)lo}	\texttt{spread}(W_{14}^{b(4)lo})	W_{14}^{b(4) hi}	\texttt{spread}(W_{14}^{b(4)hi})
0	0	0	0	0	0	0	0	1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(d)	\texttt{spread}(g)		W_{14}^{e(1)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	W_{14}^{a(3)}	\texttt{spread}(W_{14}^{a(3)})	W_{14}^{c(3)}	\texttt{spread}(W_{14}^{c(3)})	W_{14}^{f(1)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})	\sigma_1 v2 R_0	\sigma_1 v2 R_1	\sigma_1 v2 R_0^{even}	\sigma_1 v2 R_0^{odd}
..	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...
0	1	0	0	1	0	0	0	0	{0,1,2,3}	W_{49}^{d(13)}	\texttt{spread}(W_{49}^{d(13)})	W_{49}^{lo}	W_{49}^{hi}	W_{49}
0	0	0	0	0	0	0	0	0	{0,1}	W_{49}^{a(10)}	\texttt{spread}(W_{49}^{a(10)})	W_{49}^{c(2)}	W_{49}^{b(7)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	W_{49}^{b(7)lo}	\texttt{spread}(W_{49}^{b(7)lo})	W_{49}^{b(7)mid}	\texttt{spread}(W_{49}^{b(7)mid})
0	0	0	0	0	0	0	0	1	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(a)	\texttt{spread}(d)	W_{1}^{b(49)}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	W_{49}^{c(2)}	\texttt{spread}(W_{49}^{c(2)})	W_{49}^{b(7)hi}	\texttt{spread}(W_{49}^{b(7)hi})
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})	\sigma_1 v1 R_0	\sigma_1 v1 R_1	\sigma_1 v1 R_0^{even}	\sigma_1 v1 R_0^{odd}
..	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...	...
0	1	0	0	0	0	0	0	0	{0,1,2,3,4,5}	W_{62}^{lo}	\texttt{spread}(W_{62}^{lo})	W_{62}^{lo}	W_{62}^{hi}	W_{62}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	W_{62}^{hi}	\texttt{spread}(W_{62}^{hi})
0	1	0	0	0	0	0	0	0	{0,1,2,3,4,5}	W_{63}^{lo}	\texttt{spread}(W_{63}^{lo})	W_{63}^{lo}	W_{63}^{hi}	W_{63}
0	0	0	0	0	0	0	0	0	{0,1,2,3,4,5}	W_{63}^{hi}	\texttt{spread}(W_{63}^{hi})

Constraints:

• sw: construct word using reduce_4
• sd0: decomposition gate for W_0, W_{62}, W_{63}
  • W^{lo} + 2^{16} W^{hi} - W = 0
• sd1: decomposition gate for W_{1..13} (split into $(3,4,11,14)$-bit pieces)
  • W^{a(3)} + 2^3 W^{b(4) lo} + 2^5 W^{b(4) hi} + 2^7 W^{c(11)} + 2^{18} W^{d(14)} - W = 0
• sd2: decomposition gate for W_{14..48} (split into $(3,4,3,7,1,1,13)$-bit pieces)
  • W^{a(3)} + 2^3 W^{b(4) lo} + 2^5 W^{b(4) hi} + 2^7 W^{c(11)} + 2^{10} W^{d(14)} + 2^{17} W^{e(1)} + 2^{18} W^{f(1)} + 2^{19} W^{g(13)} - W = 0
• sd3: decomposition gate for W_{49..61} (split into $(10,7,2,13)$-bit pieces)
  • W^{a(10)} + 2^{10} W^{b(7) lo} + 2^{12} W^{b(7) mid} + 2^{15} W^{b(7) hi} + 2^{17} W^{c(2)} + 2^{19} W^{d(13)} - W = 0

Compression region

+----------------------------------------------------------+
|                                                          |
|          decompose E,                                    |
|          Σ_1(E)                                          |
|                                                          |
|                  +---------------------------------------+
|                  |                                       |
|                  |        reduce_5() to get H'           |
|                  |                                       |
+----------------------------------------------------------+
|          decompose F, decompose G                        |
|                                                          |
|                        Ch(E,F,G)                         |
|                                                          |
+----------------------------------------------------------+
|                                                          |
|          decompose A,                                    |
|          Σ_0(A)                                          |
|                                                          |
|                                                          |
|                  +---------------------------------------+
|                  |                                       |
|                  |        reduce_7() to get A_new,       |
|                  |              using H'                 |
|                  |                                       |
+------------------+---------------------------------------+
|          decompose B, decompose C                        |
|                                                          |
|          Maj(A,B,C)                                      |
|                                                          |
|                  +---------------------------------------+
|                  |        reduce_6() to get E_new,       |
|                  |              using H'                 |
+------------------+---------------------------------------+

Initial round:

sd_abcd	sd_efgh	ss0	ss1	s_maj	s_neg	s_ch	a_0	a_1	a_2	a_3	a_4	a_5	a_6	a_7	a_8	a_9
0	1	0	0	0	0	0	{0,1,2}	F_0 d(7)	\texttt{spread}(E_0 d(7))	E_0 b(5)^{lo}	\texttt{spread}(E_0 b(5)^{lo})	E_0 b(5)^{hi}	\texttt{spread}(E_0 b(5)^{hi})	E_0^{lo}	\mathtt{spread}(E_0^{lo})
0	0	0	0	0	0	0	{0,1}	E_0 c(14)	\texttt{spread}(E_0 c(14))	E_0 a(6)^{lo}	\texttt{spread}(E_0 a(6)^{lo})	E_0 a(6)^{hi}	\texttt{spread}(E_0 a(6)^{hi})	E_0^{hi}	\mathtt{spread}(E_0^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	\texttt{spread}(E_0 b(5)^{lo})	\texttt{spread}(E_0 b(5)^{hi})
0	0	0	1	0	0	0	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(E_0 d(7))	\texttt{spread}(E_0 c(14))
0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	\texttt{spread}(E_0 a(6)^{lo})	\texttt{spread}(E_0 a(6)^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})
0	1	0	0	0	0	0	{0,1,2}	F_0 d(7)	\texttt{spread}(F_0 d(7))	F_0 b(5)^{lo}	\texttt{spread}(F_0 b(5)^{lo})	F_0 b(5)^{hi}	\texttt{spread}(F_0 b(5)^{hi})	F_0^{lo}	\mathtt{spread}(F_0^{lo})
0	0	0	0	0	0	0	{0,1}	F_0 c(14)	\texttt{spread}(F_0 c(14))	F_0 a(6)^{lo}	\texttt{spread}(F_0 a(6)^{lo})	F_0 a(6)^{hi}	\texttt{spread}(F_0 a(6)^{hi})	F_0^{hi}	\mathtt{spread}(F_0^{hi})
0	1	0	0	0	0	0	{0,1,2}	G_0 d(7)	\texttt{spread}(G_0 d(7))	G_0 b(5)^{lo}	\texttt{spread}(G_0 b(5)^{lo})	G_0 b(5)^{hi}	\texttt{spread}(G_0 b(5)^{hi})	G_0^{lo}	\mathtt{spread}(G_0^{lo})
0	0	0	0	0	0	0	{0,1}	G_0 c(14)	\texttt{spread}(G_0 c(14))	G_0 a(6)^{lo}	\texttt{spread}(G_0 a(6)^{lo})	G_0 a(6)^{hi}	\texttt{spread}(G_0 a(6)^{hi})	G_0^{hi}	\mathtt{spread}(G_0^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	P_0^{even}	\texttt{spread}(P_0^{even})	\mathtt{spread}(E_0^{lo})	\mathtt{spread}(E_0^{hi})	\texttt{spread}(Q_0^{odd})	K_0^{lo}	H_0^{lo}	\mathtt{spread}(H_0^{lo})	W_0^{lo}
0	0	0	0	0	0	1	{0,1,2,3,4,5}	P_0^{odd}	\texttt{spread}(P_0^{odd})	\texttt{spread}(P_1^{odd})	\Sigma_1(E_0)^{lo}	\Sigma_1(E_0)^{hi}	K_0^{hi}	H_0^{hi}	\mathtt{spread}(H_0^{hi})	W_0^{hi}
0	0	0	0	0	0	0	{0,1,2,3,4,5}	P_1^{even}	\texttt{spread}(P_1^{even})	\mathtt{spread}(F^{lo})	\mathtt{spread}(F^{hi})	\texttt{spread}(Q_1^{odd})		Hprime_0^{lo}	Hprime_0^{hi}	Hprime_0 carry
0	0	0	0	0	0	0	{0,1,2,3,4,5}	P_1^{odd}	\texttt{spread}(P_1^{odd})				D_0^{lo}	E_1^{lo}	\mathtt{spread}(E_1^{lo})
0	0	0	0	0	1	0	{0,1,2,3,4,5}	Q_0^{even}	\texttt{spread}(Q_0^{even})	\mathtt{spread}(E_0^{lo})	\mathtt{spread}(E_0^{hi})		D_0^{hi}	E_1^{hi}	\mathtt{spread}(E_1^{hi})	E_1 carry
0	0	0	0	0	0	0	{0,1,2,3,4,5}	Q_0^{odd}	\texttt{spread}(Q_0^{odd})	evens_0 - \mathtt{spread}(E_0^{lo})	evens_1 - \mathtt{spread}(E_0^{hi})			D_0^{lo}	\mathtt{spread}(D_0^{lo})
0	0	0	0	0	0	1	{0,1,2,3,4,5}	Q_1^{even}	\texttt{spread}(Q_1^{even})	\texttt{spread}(Q_1^{odd})				D_0^{hi}	\mathtt{spread}(D_0^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	Q_1^{odd}	\texttt{spread}(Q_1^{odd})	\mathtt{spread}(G^{lo})	\mathtt{spread}(G^{hi})
1	0	0	0	0	0	0	{0,1,2}	A_0 b(11)	\texttt{spread}(A_0 b(11))	A_0 c(9)^{lo}	\texttt{spread}(A_0 c(9)^{lo})	A_0 c(9)^{mid}	\texttt{spread}(A_0 c(9)^{mid})	A_0^{lo}	\mathtt{spread}(A_0^{lo})
0	0	0	0	0	0	0	{0,1}	A_0 d(10)	\texttt{spread}(A_0 d(10))	A_0 a(2)	\texttt{spread}(A_0 a(2))	A_0 c(9)^{hi}	\texttt{spread}(A_0 c(9)^{hi})	A_0^{hi}	\mathtt{spread}(A_0^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_0^{even}	\texttt{spread}(R_0^{even})	\texttt{spread}(c(9)^{lo})	\texttt{spread}(c(9)^{mid})
0	0	0	1	0	0	0	{0,1,2,3,4,5}	R_0^{odd}	\texttt{spread}(R_0^{odd})	\texttt{spread}(R_1^{odd})	\texttt{spread}(d(10))	\texttt{spread}(b(11))
0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{even}	\texttt{spread}(R_1^{even})	\texttt{spread}(a(2))	\texttt{spread}(c(9)^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	R_1^{odd}	\texttt{spread}(R_1^{odd})
1	0	0	0	0	0	0	{0,1,2}	B_0 b(11)	\texttt{spread}(B_0 b(11))	B_0 c(9)^{lo}	\texttt{spread}(B_0 c(9)^{lo})	B_0 c(9)^{mid}	\texttt{spread}(B_0 c(9)^{mid})	B_0^{lo}	\mathtt{spread}(B_0^{lo})
0	0	0	0	0	0	0	{0,1}	B_0 d(10)	\texttt{spread}(B_0 d(10))	B_0 a(2)	\texttt{spread}(B_0 a(2))	B_0 c(9)^{hi}	\texttt{spread}(B_0 c(9)^{hi})	B_0^{hi}	\mathtt{spread}(B_0^{hi})
1	0	0	0	0	0	0	{0,1,2}	C_0 b(11)	\texttt{spread}(C_0 b(11))	C_0 c(9)^{lo}	\texttt{spread}(C_0 c(9)^{lo})	C_0 c(9)^{mid}	\texttt{spread}(C_0 c(9)^{mid})	C_0^{lo}	\mathtt{spread}(C_0^{lo})
0	0	0	0	0	0	0	{0,1}	C_0 d(10)	\texttt{spread}(C_0 d(10))	C_0 a(2)	\texttt{spread}(C_0 a(2))	C_0 c(9)^{hi}	\texttt{spread}(C_0 c(9)^{hi})	C_0^{hi}	\mathtt{spread}(C_0^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	M_0^{even}	\texttt{spread}(M_0^{even})	\mathtt{spread}(A_0^{lo})	\mathtt{spread}(A_0^{hi})			Hprime_0^{lo}	Hprime_0^{hi}
0	0	0	0	1	0	0	{0,1,2,3,4,5}	M_0^{odd}	\texttt{spread}(M_0^{odd})	\mathtt{spread}(B_0^{lo})	\mathtt{spread}(B_0^{hi})		\Sigma_0(A_0)^{lo}	A_1^{lo}	\mathtt{spread}(A_1^{lo})	A_1 carry
0	0	0	0	0	0	0	{0,1,2,3,4,5}	M_1^{even}	\texttt{spread}(M_1^{even})	\mathtt{spread}(C_0^{lo})	\mathtt{spread}(C_0^{hi})	\texttt{spread}(M_1^{odd})	\Sigma_0(A_0)^{hi}	A_1^{hi}	\mathtt{spread}(A_1^{hi})
0	0	0	0	0	0	0	{0,1,2,3,4,5}	M_1^{odd}	\texttt{spread}(M_1^{odd})
